BDC-HS24-30.8-10-5000-S
Ø24.4mm Brushed DC Motor
$24.80
Availability:
98 in stock
Ships in 3 to 5 business daysAbout BDC-HS24-30.8-10-5000-S
The BDC-HS24-30.8-10-5000-S is a high-quality brushed DC motor with a diameter of 24.4mm. It is designed to provide efficient and reliable performance for various applications. With a rated voltage of 10VDC, this motor offers a powerful and consistent power supply for your projects.
Featuring a compact design, the BDC-HS24-30.8-10-5000-S is perfect for space-constrained environments. Its length of 30.8mm ensures easy integration into your system without compromising on performance. This motor is capable of delivering a no-load speed of 5000 RPM, allowing for quick and precise movements.
The BDC-HS24-30.8-10-5000-S is equipped with a brushed motor type, which ensures smooth and reliable operation. Its rated torque of 0.047 kg.cm and rated speed of 4300 RPM make it suitable for a wide range of applications, including robotics, automation, and DIY projects.
With a stall torque of 0.3 kg.cm and stall current of 2.25 A, this motor can handle demanding tasks with ease. Whether you need to lift heavy loads or perform precise movements, the BDC-HS24-30.8-10-5000-S is up to the challenge. Its high-quality construction ensures durability and longevity, making it a reliable choice for your projects.
Product Specifications
| Description | Value |
|---|---|
| Voltage | 10 |
| Voltage Type | VDC |
| Diameter (mm) | 24.4 |
| Length (mm) | 30.8 |
| No Load Speed (rpm) | 5000 |
| No Load Current (A) | 0.08 |
| Rated Torque (kg.cm) | 0.05 |
| Rated Speed (rpm) | 4300 |
| Stall Torque (kg.cm) | 0.30 |
| Stall Current (A) | 2.25 |
| Gearhead Type | None |
| Motor Type | Brushed |
| Series | HS24 |
| Reference ID | MOT-HS24-18210 |
2D Drawing for BDC-HS24-30.8-10-5000-S and Datasheet
Below you will find links to the 2D technical drawing, along with the datasheet, if they are available for download.
If either the drawing or datasheet is not available, you may submit a request to ISL Products International below.
Frequently Asked Questions
General
The BDC-HS24-30.8-10-5000-S is a high-quality brushed DC motor designed for various applications. It features a compact size with a diameter of 24.4mm and a length of 30.8mm, making it ideal for space-constrained designs. This motor offers reliable and efficient performance, ensuring consistent operation and reducing the risk of downtime in your projects.
The BDC-HS24-30.8-10-5000-S motor operates on a voltage of 10VDC. This voltage level provides a good balance between power and efficiency, suitable for a wide range of applications.
The operating voltage of the BDC-HS24-30.8-10-5000-S motor is 10VDC. This standard voltage level makes it compatible with a wide range of power sources, ensuring flexibility in various applications.
Performance
The no-load speed of the motor is 5000 RPM. This high-speed capability ensures quick and efficient operation, making it suitable for applications requiring fast and reliable performance.
The motor has a rated torque of 0.05 kg.cm and a rated speed of 4300 RPM. This means it can deliver consistent and reliable power output, making it ideal for applications that require steady and efficient performance under load conditions.
The BDC-HS24-30.8-10-5000-S motor has a stall torque of 0.30 kg.cm and a stall current of 2.25A. These specifications indicate the motor's ability to handle heavy loads and demanding applications, ensuring reliable performance even under high-stress conditions.
Applications
The BDC-HS24-30.8-10-5000-S motor is versatile and can be used in various applications including robotics, automation, and other projects that require a compact and efficient motor. Its small size and high performance make it perfect for space-constrained applications where power and efficiency are crucial.
Yes, the BDC-HS24-30.8-10-5000-S motor is specifically designed for space-constrained applications. Its compact size allows for easy integration into designs where space is limited, without compromising on performance and efficiency.
Additional Information
The price of the BDC-HS24-30.8-10-5000-S motor is available at the top of this page. Higher quantity and bulk pricing are available upon request. Please contact our sales team for the most accurate and up-to-date pricing information.
Yes, bulk discounts are available. Please contact our sales team for additional information. For example, purchasing 100 units can significantly reduce the price per unit. Please refer to the bulk discount pricing table available on the product page. This table provides pricing details for different quantities, helping you make cost-effective decisions based on your order size.
For more information about the BDC-HS24-30.8-10-5000-S motor, including detailed specifications, please refer to the Drawing/Datasheet section on the product page on our website.
